ISTA Electrodynamic Vibration Shaker , 1200N Shaker Test Equipment
Product Details
| Shock Force: | 1200N | Vibration Direction: | Veritical Horizontal Vibration Test |
|---|---|---|---|
| Standard: | ISTA Standard | Application: | Packaging |
| Displacement: | 25mm | Acceleration: | 100g |
| Highlight |
1200N electrodynamic vibration shaker,vibration test equipment with warranty,ISTA shaker test equipment |
||
Product Description
The ASLI Brand Energy Saving Electrodynamic Shaker Vibrator is designed to meet ISTA standards for vibration testing. This system is specifically engineered for battery-related testing, simulating real-world vibration conditions to evaluate battery performance and safety.
During testing, the battery or battery pack is securely fixed to the vibration table and subjected to prescribed frequency, acceleration, and displacement modes along three mutually perpendicular directions. The battery sample must not leak, lose voltage, sustain damage, catch fire, or explode under these conditions.
For detailed specifications, please refer to the downloadable document: vibration test chamber ES-6.pdf
| Model | Rated Sine Force (N) | Rated Random Force (N) | Frequency Range (Hz) | Rated Acceleration (m/s²) | Rated Speed (m/s) | Rated Displacement (p-p) mm | Max. Loading (Kg) | Moving Coil (Kg) | Dimension of Moving Coil (mm) |
|---|---|---|---|---|---|---|---|---|---|
| ES-3 | 3000 | 3000 | 3–3500 | 1000 | 1.6 | 25 | 100 | 3.5 | Φ150 |
| ES-3a | 3000 | 3000 | 3–3500 | 400 | 1.6 | 40 | 120 | 9 | Φ230 |
| ES-6 | 6000 | 6000 | 3–3500 | 1000 | 1.6 | 25 | 180 | 6.5 | Φ230 |
| ES-6a | 6000 | 6000 | 3–3500 | 1000 | 1.6 | 51 | 250 | 12 | Φ230 |
| ES-10 | 10000 | 10000 | 3–3000 | 1000 | 1.8 | 51 | 270 | 14 | Φ240 |
| ES-20 | 20000 | 20000 | 3–3000 | 1000 | 1.8 | 51 | 300 | 30 | Φ320 |
| ES-30 | 30000 | 30000 | 3–2800 | 1000 | 1.8 | 51 | 450 | 40 | Φ450 |
| ES-40 | 40000 | 40000 | 3–2800 | 1000 | 1.8 | 51 | 500 | 50 | Φ450 |
| ES-50 | 50000 | 50000 | 3–2700 | 1000 | 1.8 | 51 | 750 | 50 | Φ450 |
| ES-60 | 60000 | 60000 | 3–2700 | 1000 | 1.8 | 51 | 750 | 60 | Φ450 |
- GB/T 31486-2015 — Electrical performance requirements and test methods for traction battery of electric vehicle
- UL 1642:2012 — Standard for Lithium batteries
- UL 2054:2012 — Household and Commercial Batteries
- UN38.3 (2012) — Part 3: Proposal for dangerous goods transport – test and standard manual
- IEC 62133-2:2017 — Safety requirements for portable sealed secondary cells, and for batteries made from them, for use in portable applications – Part 2: Lithium systems
- IEC 62281:2004 — The safety requirements in transport of Lithium battery and battery
- IEC 60086:2007 — Galvanic cell part 4: The security requirements of lithium-ion batteries
In addition to vibration test benches, our product portfolio includes:
- Temperature / Humidity Test Series: Temperature humidity test chamber, Walk-in stability chamber, Thermal shock test chamber, Temperature humidity UV test chamber, Ramp rate temperature chamber.
- Aging Test Series: High temperature oven, Vacuum drying oven, Air ventilation aging test chamber, Steam aging test chamber, Ozone test chamber, Burn-in test equipment.
- Weather Simulation Test Series: Rain spray test chamber, Dust test chamber, Xenon lamp aging test chamber, UV resistance test chamber.
- Mechanical Test Series: Vibration test machine, Drop test machine, Bump test machine, Acceleration mechanical shock tester, and more.
Product Highlights
ISTA-compliant 1200N electrodynamic vibration shaker for packaging tests, offering 25mm displacement, 100g acceleration, and vertical/horizontal vibration. Durable, energy-saving, and customizable to meet UL, UN38.3, and IEC standards.
