Electromagnetic Shaker Vibration Tester Machine with 1 Year Warranty 3.5kg Moving Coil and 3kw Cooling Fan
Product Details
| Max. Speed: | 1.6m/s | Moving Coil Weight: | 3.5 Kg |
|---|---|---|---|
| Cooling Fan Power: | 3kw | Power Supply: | AC380V |
| Vibration Direction: | Vertical+horizontal | Rated Sine Force: | 3000 N |
| Rated Random Force: | 3000 N | Frequency Range: | 3-3500 Hz |
| Rated Acceleration: | 1000 M/s2 | Rated Displacement: | 25 Mm |
| Max. Loading: | 100 Kg | Moving Coil Diameter: | Φ150 Mm |
| Power Type: | Electronic | Rated Speed: | 1.6 M/s |
| Moving Coil Dimension: | Φ150 Mm | ||
| Highlight |
1 Year Warranty Vibration Tester Machine,3.5kg Moving Coil Electromagnetic Shaker,3kw Cooling Fan Vibration Shaker System |
||
Product Description
The Electromagnetic Shaker Vibration Tester Machine is a high-performance testing system designed for precise simulation of vibration and shock environments. It is widely used in aerospace, automotive, electronics, and packaging industries to evaluate product reliability and structural integrity under dynamic stress conditions.
| Model | Rated Sine Force (N) | Rated Random Force (N) | Frequency Range (Hz) | Rated Acceleration (m/s²) | Rated Speed (m/s) | Rated Displacement (p-p) mm | Max. Loading (Kg) | Moving Coil (Kg) | Dimension of Moving Coil (mm) |
|---|---|---|---|---|---|---|---|---|---|
| ES-3 | 3000 | 3000 | 3–3500 | 1000 | 1.6 | 25 | 100 | 3.5 | Φ150 |
| ES-3a | 3000 | 3000 | 3–3500 | 400 | 1.6 | 40 | 120 | 9 | Φ230 |
| ES-6 | 6000 | 6000 | 3–3500 | 1000 | 1.6 | 25 | 180 | 6.5 | Φ230 |
| ES-6a | 6000 | 6000 | 3–3500 | 1000 | 1.6 | 51 | 250 | 12 | Φ230 |
| ES-10 | 10000 | 10000 | 3–3000 | 1000 | 1.8 | 51 | 270 | 14 | Φ240 |
| ES-20 | 20000 | 20000 | 3–3000 | 1000 | 1.8 | 51 | 300 | 30 | Φ320 |
| ES-30 | 30000 | 30000 | 3–2800 | 1000 | 1.8 | 51 | 450 | 40 | Φ450 |
| ES-40 | 40000 | 40000 | 3–2800 | 1000 | 1.8 | 51 | 500 | 50 | Φ450 |
| ES-50 | 50000 | 50000 | 3–2700 | 1000 | 1.8 | 51 | 750 | 50 | Φ450 |
| ES-60 | 60000 | 60000 | 3–2700 | 1000 | 1.8 | 51 | 750 | 60 | Φ450 |
| ES-100 | 100000 | 100000 | 3–2500 | 1000 | 1.8 | 51 | 1000 | 90 | Φ450 |
| ES-120 | 120000 | 120000 | 3–2200 | 1000 | 1.8 | 51 | 1100 | 90 | Φ500 |
Package: PP film first, then 10mm foam between machine and the case, and outside is a standard export plywood case.
- High quality guarantee.
- Shipment with professional documents.
- Packing as your request, with photo before shipment.
- Reply within 48 hours and provide solution within 3 working days.
- Professional after-service from our engineers.
- Warranty period: 12 months.
- Client is first. We are trying to bring maximum profit to our clients and offer best quality products.
- Credibility is the most important.
- Quality control is our life.
- Great sense of responsibility.
About ASLi Factory: We are a long-established testing equipment manufacturer. Over the past 28 years, we have devoted ourselves to simulation environmental testing equipment and mechanical vibration and shock testing machines. The vertical mechanical vibration testing machine is one of our star products, and we have obtained CE certification for this machine.
Temperature Humidity Test Chamber | Acceleration Mechanical Shock Tester | Salt Spray Test Chamber
If you need more information about the Electromagnetic Shaker Vibration Tester Machine, please don't hesitate to send your inquiry.
Product Highlights
Electromagnetic Shaker Vibration Tester Machine delivers 3000N sine/random force, 3-3500Hz, 1000m/s², 100kg load. CE certified, 28-year manufacturer, 12-month warranty, export plywood packing, custom options available.
