Factory Price Electrodynamic Shaker Vibration Testing Machine with AC380V Power 1 Year Warranty and Max Speed 1.6m/s
Product Details
| Max. Speed: | 1.6m/s | Moving Coil Weight: | 3.5 Kg |
|---|---|---|---|
| Cooling Fan Power: | 3kw | Rated Sine Force: | 3000 N |
| Rated Random Force: | 3000 N | Frequency Range: | 3-3500 Hz |
| Rated Acceleration: | 1000 M/s2 | Rated Speed: | 1.6 M/s |
| Rated Displacement: | 25 Mm | Max. Loading: | 100 Kg |
| Moving Coil Dimension: | Φ150 Mm | Power Supply: | AC380V |
| Moving Coil Weight Range: | 3.5-90 Kg | Frequency Range Max: | 3500 Hz |
| Rated Acceleration Max: | 1000 M/s2 | ||
| Highlight |
AC380V Electrodynamic Shaker,1 Year Warranty Vibration Testing Machine,Max Speed 1.6m/s Electrodynamic Shaker |
||
Product Description
The factory price electrodynamic shaker is a high-performance vibration testing system designed for simulation of environmental and mechanical vibration and shock conditions. It delivers reliable, repeatable results for product qualification, reliability testing, and quality assurance across a wide range of industries.
| Model | Rated Sine Force (N) | Rated Random Force (N) | Frequency Range (Hz) | Rated Acceleration (m/s²) | Rated Speed (m/s) | Rated Displacement (p-p) mm | Max. Loading (Kg) | Moving Coil (Kg) | Dimension of Moving Coil (mm) |
|---|---|---|---|---|---|---|---|---|---|
| ES-3 | 3000 | 3000 | 3–3500 | 1000 | 1.6 | 25 | 100 | 3.5 | Φ150 |
| ES-3a | 3000 | 3000 | 3–3500 | 400 | 1.6 | 40 | 120 | 9 | Φ230 |
| ES-6 | 6000 | 6000 | 3–3500 | 1000 | 1.6 | 25 | 180 | 6.5 | Φ230 |
| ES-6a | 6000 | 6000 | 3–3500 | 1000 | 1.6 | 51 | 250 | 12 | Φ230 |
| ES-10 | 10000 | 10000 | 3–3000 | 1000 | 1.8 | 51 | 270 | 14 | Φ240 |
| ES-20 | 20000 | 20000 | 3–3000 | 1000 | 1.8 | 51 | 300 | 30 | Φ320 |
| ES-30 | 30000 | 30000 | 3–2800 | 1000 | 1.8 | 51 | 450 | 40 | Φ450 |
| ES-40 | 40000 | 40000 | 3–2800 | 1000 | 1.8 | 51 | 500 | 50 | Φ450 |
| ES-50 | 50000 | 50000 | 3–2700 | 1000 | 1.8 | 51 | 750 | 50 | Φ450 |
| ES-60 | 60000 | 60000 | 3–2700 | 1000 | 1.8 | 51 | 750 | 60 | Φ450 |
| ES-100 | 100000 | 100000 | 3–2500 | 1000 | 1.8 | 51 | 1000 | 90 | Φ450 |
| ES-120 | 120000 | 120000 | 3–2200 | 1000 | 1.8 | 51 | 1100 | 90 | Φ500 |
Package: PP film first, then 10mm foam between the machine and the case, and outside is a standard export plywood case.
- High quality guarantee.
- Shipment with professional documents.
- Packing as your request, with photo before shipment.
- Reply within 48 hours and provide solution within 3 working days.
- Professional after-service from our engineers.
- Warranty period: 12 months.
- Client is first. We are trying to bring maximum profit to our clients and offer best quality products.
- Credibility is the most important.
- Quality control is our life.
- Great sense of responsibility.
We are a long-established testing equipment manufacturer. Over the past 28 years, we have devoted ourselves to simulation environmental testing equipment and mechanical vibration and shock testing machines. The factory price electrodynamic shaker is our star product, and we have obtained CE certification for this machine.
A: PP film first, then 10mm foam between the machine and the case, and outside is a standard export plywood case.
A: T/T 50% as deposit, and 50% before delivery. We will show you the photos of the products and packages before you pay the balance.
A: EXW, FOB, CIF.
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Product Highlights
ASLi factory price electrodynamic shaker: 3-3500Hz, 3000N sine/random force, 1000m/s² acceleration, 100kg max load. CE certified, 28 years manufacturer, 12-month warranty, export plywood packing, custom options available.
