High Frequency Electrodynamic Vibration Shaker with PC Control 20000N Rated Force and Customized Support

Brand Name: ASLI
Model Number: ES-20
Place of Origin: Guangdong, China
Minimum Order Quantity: 1

Product Details


Vibration Method: Sine & Random Vibration Rated Sine Force: 20000N
Rated Random Force: 20000N Frequency Range: 3~3500HZ
Max. Acceleration: 100g Rated Speed: 2.0m/s
Rated Displacement: 51mm Control Method: PC
Vibration Direction: Vertical Vibration Power Supply: AC380V
Max. Loading: 300Kg Moving Coil Weight: 30Kg
Moving Coil Dimension: Φ320 Axial Resonance Frequency: High
Cooling Effect: Enhanced
Highlight

PC Control Electrodynamic Vibration Shaker

,

20000N Rated Force Vibration Testing Machine

,

Customized Support Vibration Test System

Product Description

Application

We are a manufacturer of the High Frequency Vibration Test Machine series. Our products adopt advanced modern technologies including a double-magnetic circuit structure, self-generated skeleton action circles, airborne support, roller bearings and linear guidance, and trunnion isolation. These systems can perform X, Y, and Z three-axis sinusoidal vibration tests and broadband random vibration tests, as well as classical pulse tests (half-sine, trapezoidal, sawtooth wave) and shock response spectrum tests.

These products are widely used in national defense, weapons, aviation, aerospace, communications, electronics, electrical appliances, and home appliances industries.

High Frequency Vertical and Horizontal Electrodynamics Vibration Testing Machine — full system view
Technical Parameters
Model Rated Sine Force (N) Rated Random Force (N) Frequency Range (Hz) Rated Acceleration (m/s²) Rated Speed (m/s) Rated Displacement (p-p) mm Max. Loading (Kg) Moving Coil (Kg) Dimension of Moving Coil (mm)
ES-1100010003–35004001.225702.5Φ150
ES-2200020003–35008001.625702.5Φ150
ES-2a200020003–35003001.640708Φ230
ES-3300030003–350010001.6251003.5Φ150
ES-3a300030003–35004001.6401209Φ230
ES-6600060003–350010001.6251806.5Φ230
ES-6a600060003–350010001.65125012Φ230
ES-1010000100003–300010001.85127014Φ240
ES-2020000200003–300010001.85130030Φ320
ES-3030000300003–280010001.85145040Φ450
ES-4040000400003–280010001.85150050Φ450
ES-5050000500003–270010001.85175050Φ450
ES-6060000600003–270010001.85175060Φ450
ES-1001000001000003–250010001.851100090Φ450
ES-1201200001200003–220010001.851110090Φ500
ES-1601600001600003–210010001.8511500150Φ600
ES-2002000002000003–200010001.8512500200Φ650
ES-3503500003500003–170010001.8514500300Φ87
Key Features
  1. Well-designed dynamic circle skeleton with a higher stage axial resonance frequency.
  2. Two-magnetic circuit design with low magnetic flux leakage, compact structure, and rational layout.
  3. Rocker rod roller bearings with straight and import-oriented composite body stiffness orientation, providing excellent eccentric load capacity.
  4. Trunnion isolation foundation dedicated to hormone use, offering convenient mobile installation.
  5. Advanced technology move-around system ensures high reliability of the dynamic circle.
  6. New duct design enhances the cooling effect.
  7. Static stiffness and dynamic stiffness of the bearing small balloon raise the vibration table capacity and improve low-frequency performance.
Expander Technical Parameters
Horizontal Expander
Technical parameters diagram for the horizontal expander of the electrodynamic vibration testing machine
Vertical Expander
Technical parameters diagram for the vertical expander of the electrodynamic vibration testing machine
Product Pictures
High Frequency Vertical and Horizontal Electrodynamics Vibration Testing Machine — front view
High Frequency Vertical and Horizontal Electrodynamics Vibration Testing Machine — side view
Packaging & Shipping
Certifications
  • China official 3rd party calibration report
  • CE certification
Packaging Process
  1. PP film first
  2. Vacuum package
  3. PP film again
  4. 10mm thickness PU foam to avoid collision
  5. Strengthened plywood case
  6. Standard ASLI case mark
Packing & Shipping Detail
Packing and shipping detail for the vibration testing machine, showing plywood case packaging
Our Services
Service Guarantee
  1. High quality guarantee.
  2. Shipment with professional documents.
  3. Packing as your request, with photo before shipment.
  4. Reply within 48 hours and provide solution within 3 working days.
  5. Professional after-service from our engineers.
  6. Warranty period: 12 months.
Customer Visits to ASLI Company
Customers visiting the ASLI company facility for the vibration testing machine
Our Advantages
  1. Professional technology support.
  2. Full experience of large numbers of container loading in Chinese sea port.
  3. Fast shipment by reputed shipping line.
  4. Best service after shipment with emails.
  5. We are a professional test equipment manufacturer in China with excellent experience and skills, also offering best quality products.
Exhibition
ASLI company exhibition booth displaying vibration testing equipment
Certifications
CE certification for the High Frequency Vertical and Horizontal Electrodynamics Vibration Testing Machine
Calibration report certificate for the vibration testing machine
Company Information

We are a long-established testing equipment manufacturer. Over the past 28 years, we have devoted ourselves to simulation environmental testing equipment and mechanical vibration and shock testing machines. The High Frequency Vertical and Horizontal Electrodynamics Vibration Testing Machine is one of our star products, and we have obtained CE certification for this machine.

ASLI factory overview showing manufacturing facilities for testing equipment
ASLi Main Test Equipment

Environmental chambers, temperature (humidity) chambers, thermal shock chambers, PCT/HAST chambers (Highly Accelerated Stress Test chambers), ESS chambers, walk-in stability chambers, vacuum ovens, electrodynamic vibration shakers, mechanical shock testers, environmental combined vibration chambers, and more.

FAQ
1. Are you a trading company or a factory?

We are a factory with 28 years focusing on the test instruments field and 4 years of exporting experience.

2. After an order is placed, when will you deliver?

Generally about 20 days. If we have finished products in stock, we can arrange shipment within 3 days. Please be aware that our production lead times depend on specific items and item quantities.

3. What about the warranty and after-sales services?

12 months warranty. After the warranty period, our professional after-sale service team will provide perfect technical support and help customers solve problems encountered while using our products. We handle guest problems and complaints in a professional and timely manner.

Relative Product
Related product from ASLI — environmental combined vibration chamber

Please feel free to contact us if you have any questions or needs regarding the High Frequency Vertical and Horizontal Electrodynamics Vibration Testing Machine.

Product Highlights

High-frequency electrodynamic vibration tester with 20kN sine/random force, 3-3500Hz range, 100g acceleration, and 300kg max load. Features dual magnetic circuit, enhanced cooling, and PC control for reliable sine, random, and shock testing. CE certified with 12-month warranty.
