| Model | OA-80 | OA-408 | OA-800 |
|---|---|---|---|
| Internal Dimensions WxHxD (mm) | 400x500x400 | 600x850x800 | 1000x1000x800 |
| External Dimensions WxHxD (mm) | 950x1650x950 | 1200x1950x1350 | 1600x2000x1450 |
| Temperature Range | RT+10ºC~+65ºC | ||
| Temperature Control Accuracy | ±0.5ºC | ||
| Temperature Distribution Uniformity | ±2.0ºC | ||
| Temperature Analytic Accuracy | 0.1ºC | ||
| Ozone Concentration | 1~1000pphm, adjustable | ||
| Ozone Concentration Deviation | ≤10% | ||
| Ozone Generator | Silent discharge tube type | ||
| Construction Materials | Inner box: SUS 304# stainless steel Outer box: Stainless steel or painted cold-rolled steel |
||
| Insulation Material | Polyurethane rigid foam / superfine glass fiber cotton | ||
| Safety Features | Leakage, short circuit, over-current protection | ||
| Power Supply | AC 220V | ||
