| Model | TH-408(A~F) | TH-800(A~F) | TH-1000(A~F) |
|---|---|---|---|
| Internal Dimension W×H×D (mm) | 600×850×800 | 1000×1000×800 | 1000×1000×1000 |
| External Dimension W×H×D (mm) | 1200×1950×1350 | 1600×2000×1450 | 1600×2100×1450 |
| Temperature Range | Low Temperature (A:25°C B:0°C C:-20°C D:-40°C E:-60°C F:-70°C) High Temperature: 150°C |
||
| Humidity Range | 20%~98% R.H. (10%-98% R.H. / 5%-98% R.H optional, requires Dehumidifier) | ||
| Control Accuracy | ±0.5°C; ±2.5% R.H. | ||
| Temperature Rising/Falling Velocity | Rising: 0.1~3.0°C/min Falling: 0.1~1.0°C/min (Min.1.5°C/min optional) |
||
| Optional Accessories | Inner door with operation hole, Recorder, Water Purifier, Dehumidifier | ||
| Power | AC380V 3 phase 5 lines, 50/60HZ | ||
Climate test chamber packaging includes:
ASLi is a professional testing equipment manufacturer with 25 years of experience specializing in environmental testing equipment and mechanical vibration/shock testing machines. Our HAST Un-Saturated Steam Chamber is CE certified.
