| Model | RT-1000A |
|---|---|
| Test Standards | JIS, ISO, IEC60529, DIN40050, GB2423, GB4208 |
| Internal Dimensions (W×H×D) | 1000×1000×1000 mm |
| External Dimensions (W×H×D) | 1600×1900×1400 mm |
| JIS Test Parameters | Flow: 1.8-3.9 L/min Pressure: 0.1-0.3 kgf/cm² |
| Drop Test | 1-1.5 mm/min adjustable IPx1/IPx2 compliant |
| Rain/Swing Pipe Test | RT~±80°C swing 0.07 L/min per nozzle IPx3/IPx4 compliant |
| Water Spray Test | 2.5-3m jet 12.5-100 L/min flow |
| High Pressure Jet Test | 80-100 kgf pressure 14-16 L/min flow IPx9K compliant |
| Rotating Plate Speed | 4-20 RPM adjustable |
