| Model | TH-1000 (A~F) |
|---|---|
| Internal Dimensions (W×H×D) | 1000×1000×1000 mm |
| External Dimensions (W×H×D) | 1200×1900×1300 mm |
| Temperature Range | Low Temperature (A:25°C, B:0°C, C:-20°C, D:-40°C, E:-60°C, F:-70°C) to High Temperature 150°C |
| Humidity Range | 20%~98% R.H. (10%-98% R.H. / 5%-98% R.H optional with dehumidifier) |
| Resolution/Distribution Uniformity | 0.1°C; 0.1% R.H./±2.0°C; ±3.0% R.H. |
| Control Accuracy | ±0.5°C; ±2.5% R.H. |
| Temperature Change Rate | Rising: 0.1~3.0°C/min; Falling: 0.3~1.0°C/min (1.5°C/min falling optional) |
| Construction Materials | Interior: SUS 304# stainless steel; Exterior: Stainless steel or painted SEE cold-rolled steel |
| Insulation | High-temperature resistant, high-density formate chlorine ethyl acetum foam |
| Cooling System | Wind or water cooling (single segment compressor for -40°C, double segment for -70°C) |
| Protection Devices | Comprehensive safety system including fuse-free switch, compressor protection, coolant protection, over-humidity/temperature protection, and fault warning |
