| Model | DTH-80A | DTH-80B | DTH-80C |
|---|---|---|---|
| Internal Dimensions WxHxD (mm) | 400×500×400 | ||
| External Dimensions WxHxD (mm) | 1150×1150×1050 | ||
| Temperature Range | (RT+10°C) ~+150°C | 0~+150°C | -20 ~+150°C |
| Humidity Range | 20%~98% R.H. | ||
| Analytic Accuracy / Distribution Uniformity of Temperature & Humidity | 0.1°C; 0.1% R.H / ±2.0°C; ±3.0% R.H. | ||
| Control Accuracy of Temperature & Humidity | ±0.5°C; ±2.5% R.H. | ||
| Temperature Rising/Speed Rate | Temperature rising approx. 0.1~3.0°C/min; temperature falling approx. 0.1~1.5°C/min | ||
| Internal and External Material | Material of the inner box is SUS 304# stainless steel, of the outer box is stainless steel or SEE cold-rolled steel with paint coated | ||
| Insulation Material | Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials | ||
| Cooling System | Wind cooling | ||
| Protection Devices | Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection | ||
| Optional Accessories | Inner door with operation hole (Optional), Recorder (optional), Water Purifier | ||
| Compressor | French Tecumseh Brand, Germany Bizer Brand | ||
| Power | AC 220V, 1ph 3 Lines, 50/60HZ | ||
| Weight (Kg) | 75 | ||
