| Model | THR-volume (low-temperature options: A ~ F) |
|---|---|
| Inner Dimensions | Customer designated space size and design |
| Temperature Range | Low Temperature (A:25°C B:0°C C:-20°C D:-40°C E:-60°C F:-70°C) High Temperature 80°C (80°C ~200°C optional) |
| Humidity Range | 20%~98%R.H. (10%-98% R.H. / 5%-98% R.H special optional, requires dehumidifier) |
| Indication Resolution/Distribution Uniformity | 0.1°C; 0.1% R.H/±2.5°C; ±3.5% R.H. |
| Control Accuracy | ±0.5°C; ±2.5% R.H. |
| Temperature Rising/Falling Velocity | Rising: approx. 0.1~3.0°C/min Falling: approx. 0.1~1.0°C/min (Minimum 1.0°C/min falling velocity optional) |
| Cooling System | Water cooled |
| Protection Devices | Fuse-free switch, compressor overloading protection, high/low voltage coolant protection, over-humidity & over-temperature protection, fuses, fault warning system, water shortage warning |
| Optional Accessories | Slope for cart, Recorder, Water Purifier, Dehumidifier |
| Compressor | French Tecumseh Brand, Germany Bizer Brand |
| Power | AC 380 V(±10%),50/60HZ, 3 ph 5 Lines |
