| Parameter | Specification |
|---|---|
| Model | TH-80 (A~F) |
| Internal Dimension W×H×D (mm) | 400×500×400 |
| External Dimension W×H×D (mm) | 950×1650×950 |
| Temperature Range | Low Temperature (A:25°C B:0°C C:-20°C D:-40°C E:-60°C F:-70°C) / High Temperature 150°C |
| Humidity Range | 20%~98% R.H. (10%-98% R.H. / 5%-98% R.H optional, requires dehumidifier) |
| Indication Resolution / Distribution Uniformity | 0.1°C; 0.1% R.H / ±2.0°C; ±3.0% R.H. |
| Control Accuracy | ±0.5°C; ±2.5% R.H. |
| Temperature Rising/Falling Velocity | Rising: 0.1~3.0°C/min; Falling: 0.3~1.0°C/min (Min. 1.5°C/min falling optional) |
| Material Construction | Interior: SUS 304# stainless steel; Exterior: Stainless steel or cold-rolled steel with paint coating |
| Insulation Material | High-temperature resistant, high-density foam insulation materials |
| Cooling System | Wind cooling or water cooling (single segment compressor -40°C, double segment compressor -70°C) |
| Protection Devices | Fuse-free switch, compressor overload protection, high/low pressure coolant protection, over-humidity/temperature protection, fuses, fault warning system, water shortage protection |
