Home /Products/Mechanical Shock Machine/30KN Mechanical Shock Machine , IEC 60068-2-64 Shock Test Machine

30KN Mechanical Shock Machine , IEC 60068-2-64 Shock Test Machine

1 set
MOQ
negotiable
Price
30KN Mechanical Shock Machine , IEC 60068-2-64 Shock Test Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Vibration Force: 30KN
Application: Battery
Test Standard: IEC 60068-2-64
Acceleration: 100g
Test: Shock
Input: 1 Channel
High Light:

IEC 60068-2-64 mechanical shock machine

,

30KN mechanical shock machine

,

IEC 60068-2-64 shock test machine
Basic Infomation
Place of Origin: CHINA
Brand Name: ASLI
Certification: CE, ISO, SGS
Model Number: ES-30
Payment & Shipping Terms
Packaging Details: strongly wooden case
Delivery Time: 40~50 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100 sets per quarter
Product Description



Big Displacement 100mm Vibration Testing Machine For Military Hardware Testing





Vibration testing machine Design standards:MIL-STD, DIN, ISO, ASTM, IEC, ISTA, GB, GJB, JIS, BS etc.


Vibration testing system Applications: battery, automotive,electronics,aerospace,vessel,telecommunication,optoelectronics ,instrument etc.



Vibration Test Shaker Parameter:



Model

Rated Sine

Force (N)

Rated Random

Force (N)

Frequency

Range (Hz)

 Rated Acceleration (m/s2) Rated Speed (m/s)

Rated displacement

(p-p) mm

 Max. Loading (Kg) moving coil(Kg)

Dimension of

Moving coil (mm)
ES-3 3000 3000 3-3500 1000 1.6 25 100 3.5 Φ150
ES-3a 3000 3000 3-3500 400 1.6 40 120 9 Φ230
ES-6 6000 6000 3-3500 1000 1.6 25 180 6.5 Φ230
ES-6a 6000 6000 3-3500 1000 1.6 51 250 12 Φ230
ES-10 10000 10000 3-3000 1000 1.8 51 270 14 Φ240
ES-20 20000 20000 3-3000 1000 1.8 51 300 30 Φ320
ES-30 30000 30000 3-2800 1000 1.8 5l 450 40 Φ450
ES-40 40000 40000 3-2800 1000 1.8 51 500 50 Φ450
ES-50 50000 50000 3-2700 1000 1.8 51 750 50 Φ450
ES-60 60000 60000 3-2700 1000 1.8 51 750 60 Φ450
ES-100 100000 100000 3-2500 1000 1.8 51 1000 90 Φ450
ES-120 120000 120000 3-2200 1000 1.8 51 1100 90 Φ500
ES-160 160000 160000 3-2100 1000 1.8 51 1500 150 Φ600
ES-200 200000 200000 3-2000 1000 1.8 51 2500 200 Φ650
ES-350 350000 350000 3-1700 1000 1.8 51 4500 300 Φ870



30KN Mechanical Shock Machine , IEC 60068-2-64 Shock Test Machine 030KN Mechanical Shock Machine , IEC 60068-2-64 Shock Test Machine 130KN Mechanical Shock Machine , IEC 60068-2-64 Shock Test Machine 2



vibration test machine features

  1. Strength of the suspension system and linear motion guiding, strong carrying capacity, good guiding functions, high stability.
  2. Perfect performance on amplitude variation.
  3. High efficient on D Class power conversion, 3 - Sigma peak current, provide the optimization of power consumption and minimum harmonic distortion.
  4. Rapid self-test diagnostics and chain safeguard, high high safety and reliability
  5. Air gasbag isolation damping device realize the the vibration table with no need for special foundation. Perfect reappearance vibration waveform and the reduction of vibration transmission
  6. Different application on the vertical and horizontal tables.
  7. Simple operation for the controller.



Besides vibration test bench, our product range also covers:



(1) Temperature/ humidity test series: Temperature humidity test chamber, Walk in stability, Thermal shock test chamber, Temperature Humidity UV test chamber, Ramp rate temperature chamber.
(2) Aging test series: High Temperature oven, Vacuum drying oven, Air ventilation aging test chamber, Steam aging test chamber, Ozone test chamber, Burn in test equipment
(3) Weather simulation test series: Rain spray test chamber, dust test chamber, Xenon lamp aging test chamber, UV resistance test chamber
(4) Mechanical test series: Vibration test machine, Drop test machine , Bump Test Machine, Acceleration mechanical shock tester etc.
